Постановка задачи
Написать программу на языке Turbo Prolog 2.0 для работы с базой данных пьезоматериалов.
Схема решения База данных будет содержать одну таблицу — таблицу
пьезоматериалов, столбцы которой перечислены далее:
1.Name — название пьезоматериала.
2.Source — изготовитель.
3.Density — плотность пьезоматериала.
4.Структура, содержащая константы-параметры пьезоматериала: C11E,
C12E, |
C13E, |
C33E, |
C44E, |
C11D, |
C12D, |
C13D, |
C33D, |
C44D, |
S11E, |
S12E, |
||||
S13E, |
S33E, |
S44E, |
S11D, |
S12D, |
S13D, |
S33D, |
S44D, |
E31, |
E33, |
E15, |
D31, |
|||
D33, D15, H31, H33, H15, G31, G33, G15, E11S, E33S, E11T, E33T.
Предполагаются следующие возможности программы:
1.Добавление пьезоматериала с консоли;
2.Добавление пьезоматериалов с CSV-файла;
3.Отображение пьезоматериалов в консоли;
4.Отображение списка изготовителей пьезоматериалов;
5.Редактирование пьезоматериалов;
6.Удаление пьезоматериала по названию;
7.Удаление всех пьезоматериалов;
8.Сохранение пьезоматериалов в CSV-файл.
2
Код программы Входные данные поступают с клавиатуры либо файла, пример
содержимого которого приведен в табл. 1.
Таблица 1 — Входные данные в файле (сверху) и описание столбцов (снизу)
P-5C;Piezotite;8;3;4;2;0.0126;-0.0047;-0.0053;0.0128;0.0316;-0.0001;0.00016;0.00027;1230;1550
P-5E;Piezotite;7.8;3;4;2;0.0124;-0.0041;-0.0052;0.0143;0.034;-0.0001;0.0002;0.0003;1490;1510
P-6C;Piezotite;7.7;3;4;2;0.0094;-0.003;-0.003;0.0103;0.0256;-8E-05;0.00019;0.00029;760;800
Название_пьезоматериала; Изготовитель_пьезоматериала; Плотность_пьезоматериала;
Номер elastic constants для ввода (CE=1, CD=2, SE=3, SD=4);
Номер piezoelectric constants для ввода (E=1, D=2, H=3, G=4);
Номер permittivities constants для ввода (ES=1, ET=2);
5 elastic constants;;;;;
3 piezoelectric constants;;;
2 permittivities constants;
Код программы приведен в табл. 2.
Таблица 2 — Код программы
NOWARNINGS
%Раздел описания доменов
DOMAINS
file = datafile reals = real*
/* const_list = cl(C11E, C12E, C13E, C33E, C44E, C11D, C12D, C13D, C33D, C44D, S11E, S12E, S13E, S33E, S44E, S11D, S12D, S13D, S33D, S44D, E31, E33, E15, D31, D33, D15, H31, H33, H15, G31, G33, G15, E11S, E33S, E11T, E33T) */
const_list = cl(real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real, real)
/* priv_const_list = pcl(C11E, C12E, C13E, C33E, C44E, E31, E33, E15, E11S, E33S, Reg_C, Reg_e, Reg_s) */ priv_const_list = pcl(real, real, real, real, real, real, real, real, real, real, integer, integer, integer) strings = string*
const_matrix = const_list*
%Раздел описания предикатов
PREDICATES if_x_equals_0_then_1_else_x(real, real)
get_ce(integer, integer, integer, const_list, const_list) get_cd(integer, integer, integer, const_list, const_list) get_se(integer, integer, integer, const_list, const_list) get_sd(integer, integer, integer, const_list, const_list) get_e(integer, integer, integer, const_list, const_list) get_d(integer, integer, integer, const_list, const_list) get_h(integer, integer, integer, const_list, const_list) get_g(integer, integer, integer, const_list, const_list) get_et(integer, integer, integer, const_list, const_list) get_es(integer, integer, integer, const_list, const_list) get_constants(priv_const_list, const_list) get_constants_aux(integer, integer, integer, const_list, const_list) get_constants_aux1(real, const_list, const_list) get_constants_aux2(real, const_list, const_list)
eq1(real, reals, reals, reals, reals, reals) eq2(real, reals, reals, reals, reals, reals) eq3(real, reals, reals, reals)
start() menu() choose(string)
insert_into_database(string, string, const_list, real) dialog_str_delete_from_database_by_name() dialog_str_clear_database()
read_real_greater_0(real)
read_variant(integer, integer, integer, integer) choose_variant(integer, integer, integer, integer, integer) dialog_str_set_elastic_constants_from_console(integer, priv_const_list)
pre_dialog_str_set_elastic_constants_from_console(integer, real, real, real, real, real) enter_elastic_constants(real, real, real, real, real, string, string, string, string, string) dialog_str_set_piezoelectric_constants_from_console(integer, priv_const_list) pre_dialog_str_set_piezoelectric_constants_from_console(integer, real, real, real) enter_piezoelectric_constants(real, real, real, string, string, string) dialog_str_set_permittivities_from_console(integer, priv_const_list) pre_dialog_str_set_permittivities_from_console(integer, real, real) enter_permittivities(real, real, string, string)
dialog_str_read_from_file() dialog_str_read_from_console() dialog_str_read_from_console_1(string, string, real) dialog_str_read_from_console_2(priv_const_list)
3
dialog_str_read_from_console_3(priv_const_list) dialog_str_read_from_console_4(priv_const_list) dialog_str_show_data()
print_database()
print_database(strings, strings, const_matrix, reals) print_enter_rows(strings, strings, const_matrix, reals) print_enter_rows(strings, strings, const_matrix, reals, string) print_consts(const_list)
dialog_str_save_into_file() print_format_consts(const_list) exists(string)
read_rows()
front_string(string, string, string) clear_database() dialog_str_show_by_source()
read_cmd(string, string, const_list, real, string) print_sources(strings, integer) remove_duplicates(strings, strings)
member(string, strings) delete3(string, strings, strings)
material_edit(string, string, const_list, real, string, string, const_list, real) choose_edit(integer, string, string, const_list, real, string, string, const_list, real) material_edited()
should_be_positive(string, real) should_be_negative(string, integer, real, integer, integer) log_str(String)
length(strings, integer) get(strings, integer, string)
%Раздел описания базы данных
DATABASE
piezomaterial(string, string, const_list, real) % piezomaterial(Name, Source, Constants, Density)
%Раздел описания внутренней цели
GOAL |
|
|
|
|
start(). |
|
|
|
|
% Раздел описания предложений |
|
|
|
|
CLAUSES |
|
|
|
|
length([], 0). |
|
|
|
|
length([_|Xs], N) :- |
|
|
|
|
length(Xs, P), |
|
|
|
|
N = P + 1. |
|
|
|
|
get([Head|_], 0, X) :- X = Head. |
|
|
|
|
get([_|Tail], I, X) :- I1 = I - 1, get(Tail, I1, X). |
|
|
||
start() :- makewindow(1, 15, 15, "Piezomaterial", 1, 0, 24, 80), menu(). |
|
|||
menu() :- |
|
|
|
|
clearwindow(), |
|
|
|
|
write(" |
************************* |
"), nl, |
||
write(" |
* |
MENU |
* |
"), nl, |
write(" |
************************* |
"), nl, |
||
write(" |
* |
1. Add from console |
* |
"), nl, |
write(" |
************************* |
"), nl, |
||
write(" |
* |
2. Add from file |
* |
"), nl, |
write(" |
************************* |
"), nl, |
||
write(" |
* |
3. Show data |
* |
"), nl, |
write(" |
************************* |
"), nl, |
||
write(" |
* |
4. Show by source |
* |
"), nl, |
write(" |
************************* |
"), nl, |
||
write(" |
* |
5. Delete by name |
* |
"), nl, |
write(" |
************************* |
"), nl, |
||
write(" |
* |
6. Clear |
* |
"), nl, |
write(" |
************************* |
"), nl, |
||
write(" |
* |
7. Save into file |
* |
"), nl, |
write(" |
************************* |
"), nl, |
||
write(" |
* |
0. Exit |
* |
"), nl, |
write(" |
************************* |
"), nl, |
||
write(" |
int>"), readln(S), clearwindow(), choose(S), menu(); menu(). |
choose(S) :- |
|
S = "0", !, exit; |
|
S = "1", !, dialog_str_read_from_console(); |
|
S = "2", !, dialog_str_read_from_file(); |
|
S = "3", !, dialog_str_show_data(); |
|
S = "4", !, dialog_str_show_by_source(); |
|
S = "5", !, dialog_str_delete_from_database_by_name(); |
|
S = "6", !, dialog_str_clear_database(); |
|
S = "7", !, dialog_str_save_into_file(). |
|
dialog_str_show_by_source() :- |
|
|
|
|
findall(Source, piezomaterial(_, Source, _, _), Sources), not(Sources = []), !, |
|
|||
write(" |
**************************** |
"), nl, |
||
write(" |
|
ENTER SOURCE |
|
"), nl, |
remove_duplicates(Sources, SList), print_sources(SList, 1), |
|
|||
write(" |
**************************** |
"), nl, |
||
length(SList, L), read_variant(N, 1, L, 0), N1 = N - 1, get(SList, N1, S), |
|
|||
findall(Name, piezomaterial(Name, _, _, _), Names), |
|
|
||
findall(Consts, piezomaterial(_, _, Consts, _), ConstsList), |
|
|||
findall(Density, piezomaterial(_, _, _, Density), Densitys), |
|
|||
print_enter_rows(Names, Sources, ConstsList, Densitys, S); |
|
|||
write(" |
*********************** |
"), nl, |
||
write(" |
* |
NO DATA! |
* |
"), nl, |
write(" |
*********************** |
"), nl, |
||
write(" |
|
any>"), readln(_). |
|
|
member(Name,[Name |_]) :- !. |
|
|
|
|
member(Name,[_ |Tail]):- member(Name,Tail). delete3(_,[],[]) :- !.
4
delete3(X,[X|T],R):- !, delete3(X,T,R). |
|
|
|
|
delete3(X,[H|T],[H|R]) :- delete3(X,T,R). |
|
|
|
|
remove_duplicates([],[]) :- !. |
|
|
|
|
remove_duplicates([H|T], [H|R]) :- |
|
|
|
|
member(H,T),!, |
|
|
|
|
delete3(H,T,R1), |
|
|
|
|
remove_duplicates(R1,R). |
|
|
|
|
remove_duplicates([H|T],[H|R]):- |
|
|
|
|
remove_duplicates(T,R). |
|
|
|
|
print_sources([], _) :- !. |
|
|
|
|
print_sources([Source|Tail], N) :- |
|
|
|
|
writef(" |
%3d. %s", N, Source), nl, N1 = N + 1, print_sources(Tail, N1). |
|||
print_enter_rows([], [], [], [], TSource) :- |
|
|
|
|
write(" |
*********************** |
"), nl, |
||
write(" |
* |
DONE! |
* |
"), nl, |
write(" |
*********************** |
"), nl, |
||
write(" |
|
any>"), readln(_). |
|
|
print_enter_rows([Name|NT], [Source|ST], [Consts|CT], [Density|DT], TSource) :- |
|
|||
Source = TSource, |
|
|
|
|
clearwindow(), |
|
|
|
|
write("*****************************************************************************"), nl, |
||||
write("* Name: ", Name), nl, |
|
|
|
|
write("* Source: ", Source), nl, |
|
|
|
|
write("* Density: ", Density), nl, |
|
|
|
|
print_format_consts(Consts), write("*****************************************************************************"), nl,
write(" |
|
next>"), readln(C), read_cmd(Name, Source, Consts, Density, C), |
||
print_enter_rows(NT, ST, CT, DT, TSource); |
|
|
||
Source = TSource, !; |
|
|
|
|
Source <> TSource, print_enter_rows(NT, ST, CT, DT, TSource). |
|
|||
insert_into_database(Name, Source, Consts, Density) :- |
|
|
||
assertz(piezomaterial(Name, Source, Consts, Density)). |
|
|
||
dialog_str_read_from_file() :- |
|
|
|
|
write(" |
**************************** |
"), nl, |
||
write(" |
* |
ENTER FILE NAME |
* |
"), nl, |
write(" |
**************************** |
"), nl, |
||
write(" |
|
string>"), readln(Filename), exists(Filename), |
|
|
openread(datafile, Filename), readdevice(datafile), read_rows(), |
|
|||
closefile(datafile), readdevice(keyboard), |
|
|
||
write(" |
********************** |
"), nl, |
||
write(" |
* |
DONE! |
* |
"), nl, |
write(" |
********************** |
"), nl, |
||
write(" |
|
any>"), !, readln(_); |
|
|
write(" |
************************** |
"), nl, |
||
write(" |
* |
MATERIALS NOT ADDED! |
* |
"), nl, |
write(" |
************************** |
"), nl, |
||
write(" |
|
any>"), readln(_). |
|
|
exists(Filename) :- |
|
|
|
|
existfile(Filename), !; |
|
|
|
|
write(" |
**************************** |
"), nl, |
||
write(" |
* |
FILE NOT FOUND |
* |
"), nl, |
write(" |
**************************** |
"), nl, |
||
write(" |
|
any>"), readln(_), !, fail. |
|
|
read_rows() :- |
|
|
|
|
not(eof(datafile)), |
|
|
|
|
readln(Line), |
|
|
|
|
front_string(Line, Name, Tail1), |
|
|
|
|
front_string(Tail1, Source, Tail2), |
|
|
|
|
front_string(Tail2, Density_STR, Tail3), str_real(Density_STR, Density),
front_string(Tail3, Reg_C_STR, Tail4), |
str_int(Reg_C_STR, Reg_C), Reg_C >= 1, Reg_C <= 4, |
front_string(Tail4, Reg_e_STR, Tail5), |
str_int(Reg_e_STR, Reg_e), Reg_e >= 1, Reg_e <= 4, |
front_string(Tail5, Reg_s_STR, Tail6), |
str_int(Reg_s_STR, Reg_s), Reg_s >= 1, Reg_s <= 2, |
front_string(Tail6, C11E_STR, Tail7), |
str_real(C11E_STR, C11E), should_be_positive(Line, C11E), |
front_string(Tail7, C12E_STR, Tail8), |
str_real(C12E_STR, C12E), should_be_negative(Line, Reg_C, C12E, 3, |
4), |
|
front_string(Tail8, C13E_STR, Tail9), |
str_real(C13E_STR, C13E), should_be_negative(Line, Reg_C, C13E, 3, |
4), |
|
front_string(Tail9, C33E_STR, Tail10), |
str_real(C33E_STR, C33E), should_be_positive(Line, C33E), |
front_string(Tail10, C44E_STR, Tail11), str_real(C44E_STR, C44E), should_be_positive(Line, C44E), |
|
front_string(Tail11, E31_STR, Tail12), |
str_real(E31_STR, E31), should_be_negative(Line, Reg_e, E31, 1, 1), |
front_string(Tail12, E33_STR, Tail13), |
str_real(E33_STR, E33), should_be_positive(Line, E33), |
front_string(Tail13, E15_STR, Tail14), |
str_real(E15_STR, E15), should_be_positive(Line, E15), |
front_string(Tail14, S11_STR, Tail15), str_real(S11_STR, E11S), should_be_positive(Line, E11S), front_string(Tail15, S33_STR, _), str_real(S33_STR, E33S), should_be_positive(Line, E33S), get_constants(pcl(C11E, C12E, C13E, C33E, C44E, E31, E33, E15, E11S, E33S, Reg_C, Reg_e, Reg_s), Consts), insert_into_database(Name, Source, Consts, Density), !, read_rows();
not(eof(datafile)), !, |
|
|
|
|
write(" |
********************************** |
"), nl, |
||
write(" |
* |
READING ERROR! |
* |
"), nl, |
write(" |
* |
REMAINING DATA WAS NOT READ! |
* |
"), nl, |
write(" |
* |
SOME MATERIALS ADDED! |
* |
"), nl, |
write(" |
********************************** |
"), nl; !. |
||
should_be_positive(Line, C1XE) :- |
|
|
|
|
C1XE > 0, !; |
|
|
|
|
write("See: ", Line), nl, |
|
|
|
|
write(" |
|
\'", C1XE, "\' should be > 0!"), nl, fail. |
|
|
should_be_negative(Line, Reg_C, C1XE, T1, T2) :- |
|
|
||
Reg_C = T1, C1XE >= 0, !, |
|
|
|
|
write("See: ", Line), nl, |
|
|
|
|
write(" |
|
\'", C1XE, "\' should be < 0!"), nl, fail; |
|
|
Reg_C = T2, C1XE >= 0, !, |
|
|
|
|
write("See: ", Line), nl, |
|
|
|
|
write(" |
|
\'", C1XE, "\' should be < 0!"), nl, fail; |
|
|
