CASE 100: PAIN IN THE LEG
History
A 22-year-old woman is admitted to hospital with a painful left leg. She uses intravenous drugs and injects into veins in the arms and the groins. The left leg has become swollen and painful over the last week. She has had two previous admissions to hospital within the last 6 months, once for an overdose of heroin and once for an infection in the left arm. She smokes 20 cigarettes daily and drinks up to 40 units of alcohol per week.
Examination
Her pulse is 84/min and regular. Her blood pressure is 124/74 mmHg. Her temperature is 37.2°C. The heart sounds are normal and there are no abnormal findings on examination of the respiratory system. She has a swollen left calf with some local tenderness. There are puncture sites in both groins but no obvious sepsis.
INVESTIGATIONS
|
|
Normal |
Haemoglobin |
12.0 g/dL |
11.7–15.7 g/dL |
White cell count |
10.8 % 109/L |
3.5–11.0 % 109/L |
Platelets |
154 % 109/L |
150–440 % 109/L |
Sodium |
137 mmol/L |
135–145 mmol/L |
Potassium |
3.8 mmol/L |
3.5–5.0 mmol/L |
Urea |
3.7 mmol/L |
2.5–6.7 mmol/L |
Creatinine |
74 &mol/L |
70–120 &mol/L |
Ultrasound of left leg: venous thrombus extending into the left femoral vein
Venous access is difficult but a line is inserted in the right arm and she is treated with subcutaneous low-molecular-weight heparin, intravenous vitamins and benzodiazepines, and a methadone-replacement regime. On the fourth day of her admission she became much more unwell.
Further examination
Her pulse is 112 per minute and regular. Her blood pressure is 88/50 mmHg although she seems warm and well perused. The respiratory rate is18/min, jugular venous pressure is not raised, there are no new heart murmurs and oxygen saturation is 97 per cent on room air. Her temperature is 37.6°C.
254
INVESTIGATIONS
|
|
Normal |
Haemoglobin |
11.4 g/dL |
11.7–15.7 g/dL |
White cell count |
18.8 % 109/L |
3.5–11.0 % 109/L |
Platelets |
197 % 109/L |
150–440 % 109/L |
Sodium |
131 mmol/L |
135–145 mmol/L |
Potassium |
4.4 mmol/L |
3.5–5.0 mmol/L |
Urea |
3.9 mmol/L |
2.5–6.7 mmol/L |
Creatinine |
79 &mol/L |
70–120 &mol/L |
C-reactive protein (CRP) |
210 mg/L |
!10 mg/L |
Question
• What is the likely diagnosis?
255
ANSWER 100
The initial diagnosis was a deep vein thrombosis. This complication is not unusual in intravenous drug users and can be associated with sepsis although there was no sign of this on the initial investigations. She has been treated for the thrombosis and for alcohol withdrawal and her opiate use.
There are a number of possibilities for her acute deterioration. The deep vein thrombosis would have predisposed her to a pulmonary embolus, but the normal respiratory rate, lack of elevation of jugular venous pressure and normal oxygen saturation make this unlikely. As an intravenous drug user she might have taken more drugs even under supervision in hospital.
The tachycardia and lowered blood pressure raise the possibility of haemorrhage which might be precipitated by the anticoagulants. However, the raised CRP, white cell count and abnormal electrolytes in a warm, well-perfused patient suggest sepsis as the likely cause. In an intravenous drug user one would think of infective endocarditis which may occur on the valves of the right side of the heart and be more difficult to diagnose. Lung abscesses from septic emboli are another possibility in an intravenous drug user with a deep vein thrombosis, and a chest X-ray should be taken although the lack of respiratory symptoms makes this less likely. In this case the intravenous line has been left in place longer than usual because of the difficulties of intravenous access and it has become infected. Lines should be inspected every day, changed regularly and removed as soon as possible. The previous hospital admissions raise then possibility of infections such as methicillin-reistant Staphylococcus aureus (MRSA). In this case MRSA was found in blood cultures and treated with intravenous vancomycin with good effect.
On recovery and discharge there were problems with the question of anticoagulation. Warfarin treatment raised difficulties because of the unreliability of dosing, attendance at anticoagulant clinics and blood sampling. It was decided to continue treatment as an outpatient with subcutaneous heparin for 6 weeks.
KEY POINTS
•Patients using intravenous drugs often pose problems in venous access, and sampling for tests such as international normalized ratio (INR).
•Indwelling venous lines should be changed regularly and removed as soon as possible.
256
INDEX
References are by case number with relevant page number(s) following in brackets. References with a page range e.g. 25(68–70) indicate that although the subject may be mentioned only on one page, it concerns the whole case.
abdominal pain/discomfort 5(14–16), 32(89–90), 36(98–9), 41(109–10), 43(113–14), 69(179–80), 72(185–6), 77(195–6), 81(205–6), 94(237–8)
abdominal sepsis, postoperative 42(112) achalasia of the cardia 55(145–6) Addison’s disease and Addisonian crisis see
adrenocortical failure adenoma, pituitary 11(28) ADH see arginine vasopressin
adrenocortical failure (Addison’s disease) 98(248)
acute, steroid-induced 71(183–4) AIDS see HIV infection
airway obstruction chronic 90(226–8)
large, rigid, differential diagnosis 99(252)
alcoholic liver disease |
7(19–20) |
||
aldosterone deficiency |
71(183–4) |
||
amenorrhoea |
30(83–4) |
|
|
aminoglycoside nephrotoxicity 42 |
|||
amnesia 62(163–4) |
|
||
amyloidosis |
22(59–61) |
|
|
anaemia |
|
|
|
iron-deficiency |
81(206) |
||
macrocytic, causes/differential diagnosis |
|||
18(46), 54(144) |
|
||
microcytic |
81(206) |
|
|
in sickle cell disease |
40(108) |
||
ankle swelling 22(59–61) |
|||
anorexia and fever |
8(21–2) |
||
anorexia nervosa |
30(83–4) |
||
antidiuretic hormone see arginine vasopressin
aortic valve disease |
93(236) |
|
appendicitis, acute |
41(109–10) |
|
arginine vasopressin (ADH; antidiuretic |
||
hormone; vasopressin) |
||
inadequate secretion |
154 |
|
inappropriate secretion |
79(200), 98(248) |
|
arterial ulcer, foot |
91(229–30) |
|
arteritis, giant cell |
82(207–8) |
|
arthritis
differential diagnosis of monoarthritis 15(38)
reactive 15(38–9) rheumatoid 27(75–7) septic see septic arthritis
ascorbic acid (vitamin C) deficiency 52(137–8)
asthma 4(11–12)
atherosclerotic renal artery stenosis 37(100) autoimmune thyroid disease 88(222) autonomic neuropathy, diabetic 87(220)
back pain 10(25–6), 31(86–8), 67(174–5) bacterial meningitis 76(193–4)
biliary disorders 5(14–16), 69(179–80), 77(195–6), 88(221–2)
blackout see consciousness, loss bleeding oesophageal varices 7(20) blisters 39(105–6)
blood, urine see haematuria
blood pressure see hypertension; hypotension bone disease, metabolic 31(86–8)
bowel disorders 6(17–18), 32(89–90), 36(99–100), 38(103–4), 41(109–10), 43(114), 63(165–6), 94(237–8)
breast cancer metastases see metastases
breathlessness (dyspnoea) 4(11), 96(241–3), |
||
99(250–3) |
|
|
chest pain and |
40(107–8), 50(130–3), |
|
78(187–8) |
|
|
cough and |
90(226–8) |
|
on exertion |
24(65–6) |
|
fever and |
25(68–70) |
|
tiredness and headaches and 18(45–6) |
||
bronchiectasis |
3(10) |
|
bruising, easy |
17(43–4) |
|
bullae (blisters) |
39(105–6) |
|
calcium disturbances 12(32) calculi see stones
cancer see malignant tumours; metastases carbon monoxide poisoning 75(191–2) carcinoid tumor 43(113–14)
carcinoma
breast, metastases see metastases
colon |
6(17–18) |
|
lung |
98(248), 99(252, 253) |
|
pancreas |
69(179–80) |
|
skin |
68(177–8) |
|
cardia, gastric (upper part of stomach) |
||
achalasia |
55(145–6) |
|
tear ()Mallory—Weiss lesion) 84(211–12)
cardiovascular disease |
1–3(3–8), 24(65–6), |
|
28(80), 50–1(130–6), 64(168–9), |
||
87(220), 92–3(231–6), 97(245–6), |
||
100(254–6) |
|
|
carotid stenosis |
83(210) |
|
central (neurogenic) diabetes insipidus |
||
58(153–5) |
|
|
cerebrovascular disease |
83(209–10) |
|
character change |
98(247–8) |
|
chest infection see respiratory tract infection
chest pain |
28(79–80), 40(107–8), 51(134–6) |
|
breathlessness and |
40(107–8), 50(130–3), |
|
73(187–8) |
|
|
cardiac |
2(6–8) |
|
non-cardiac causes |
28(80), 47(123–4) |
|
cholecystitis (gallbladder inflammation), acute 5(14–16), 77(195–6)
cholesterol, familial raised levels 97(245–6) chronic obstructive pulmonary disease
90(226–8) |
|
|
|
||
cirrhosis, primary biliary |
88(221–2) |
||||
clumsiness |
95(239–40) |
|
|
||
cluster headaches |
48(126) |
|
|||
coeliac disease |
54(143–4) |
|
|
||
colitis, ulcerative |
63(165–6) |
|
|||
collagen vascular diseases |
20(52) |
|
|||
colon |
|
|
|
|
|
carcinoma |
6(17–18) |
|
|
||
diverticulitis |
36(99–100) |
|
|||
coma |
|
|
|
|
|
differential diagnosis in diabetics |
89(224) |
||||
hyperglycaemic |
53(140), 75(192), 89(223–4) |
||||
hypoglycemic |
75(192) |
|
|
||
confusion |
74(189–90), 79(199–200) |
||||
headaches and |
33(91–2), 49(127–8) |
||||
consciousness, loss (incl. blackout) |
1(3–5), |
||||
44(115–16), 53(137–9), 61(161–2), |
|||||
75(191–2), 89(223–4) |
|
||||
convulsions see epilepsy |
|
|
|||
coronary artery disease, premature |
97(246) |
||||
see also ischaemic heart disease; myocardial infarction
corticosteroid-induced adrenal hypofunction
71(183–4) |
|
cortisol overproduction |
11(27–9) |
cough |
|
chronic or persistent |
3(9–10), 4(11, 12), |
49(127), 50(130) |
|
breathlessness and |
90(226–8) |
joint pains and 57(150–2)
syncope with |
87(220) |
Coxsackie B virus |
2(8), 24(65–6) |
cranial (giant cell) arteritis 82(207–8) |
|
cranial (neurogenic) diabetes insipidus 58(153–5)
Creutzfeld—Jakob disease 62(163–4)
Crohn’s disease 38(103–4) Cushing’s syndrome 11(27–9) cyst(s), multiple see polycystic disease cystic fibrosis 3(9–10)
deep vein thrombosis, deep 80(201–3),
|
100(254–6) |
|
|
|
|||
delirium |
74(190) |
|
|
|
|||
dementia |
62(163–4), 74(190) |
|
|||||
causes |
12(32), 62(164) |
|
|||||
dermatitis herpetiformis |
38(106) |
||||||
dermatology see skin |
|
|
|
||||
diabetes insipidus, neurogenic |
58(153–5) |
||||||
diabetes mellitus |
87(209, 210), 89(223–4) |
||||||
autonomic neuropathy |
87(220) |
||||||
diarrhoea |
|
|
|
|
|
|
|
acute |
23(63–4) |
|
|
|
|||
intermittent chronic |
63(165–6) |
||||||
dietary problems |
52(137–8) |
|
|||||
diplopia |
14(35–6) |
|
|
|
|||
dissociative disorder |
70(182–3) |
||||||
diuretic-induced hyponatraemia |
79(199–200) |
||||||
diverticulitis |
36(99–100) |
|
|||||
dizziness |
1(3–4) |
|
|
|
|||
see also vertigo |
|
|
|
||||
double vision |
14(35–6) |
|
|
||||
drowsiness 71(183–4) |
|
|
|||||
drug hypersensitivity |
65(169–70) |
||||||
drug poisoning see overdose |
|
||||||
duodenal ulcer |
|
81(205–6) |
|
||||
dysphagia (swallowing difficulty) |
55(145, 146) |
||||||
dyspnoea see breathlessness |
|
||||||
dystrophia myotonica |
14(36) |
|
|||||
eating disorder |
|
30(83–4) |
|
||||
embolism, pulmonary |
50(130–3) |
||||||
emesis |
84(211–12) |
|
|
|
|||
endocarditis, infective |
93(234–6) |
||||||
endocrine and metabolic disorders |
|||||||
|
11–12(27–32), 21(55–7), 31(86–8), |
||||||
|
53(137–9), 71(183–4), 75(192), |
||||||
|
85(213–14) |
|
|
|
|||
epilepsy (and epileptic seizures) |
34(93–4), |
||||||
|
61(161–2) |
|
|
|
|
||
focal |
83(210) |
|
|
|
|
||
erythema multiforme |
38(106) |
|
|||||
severe |
65(169–70) |
|
|
|
|||
erythema nodosum 38(103–4) |
|
||||||
falls, recurrent |
|
87(218–20) |
|
||||
fatigue see tiredness |
|
|
|
||||
fever |
19(47–8), 78(197–8) |
|
|||||
anorexia and |
8(21–2) |
|
|
||||
breathlessness and |
25(68–70) |
||||||
differential diagnosis |
20(52) |
|
|||||
fatigue and |
20(50–2) |
|
|
||||
258
