E.2 Retired Command Fields
ThefollowingcommandfieldshavebeenretiredbutarelistedhereforcompatibilitywithpreviousversionsofthisStandard.Reference PS3.5 for more information on retired Data Elements and Command Elements.
Table E.2-1. Retired Command Fields
Tag |
Message Field |
Keyword |
VR |
VM |
(0000,0001) |
Command Length to End |
CommandLengthToEnd |
UL |
1 |
(0000,0010) |
Command Recognition Code |
CommandRecognitionCode |
SH |
1 |
(0000,0200) |
Initiator |
Initiator |
AE |
1 |
(0000,0300) |
Receiver |
Receiver |
AE |
1 |
(0000,0400) |
Find Location |
FindLocation |
AE |
1 |
(0000,0850) |
Number of Matches |
NumberOfMatches |
US |
1 |
(0000,0860) |
Response Sequence Number |
ResponseSequenceNumber |
US |
1 |
(0000,4000) |
Dialog Receiver |
DialogReceiver |
LT |
1 |
(0000,4010) |
Terminal Type |
TerminalType |
LT |
1 |
(0000,5010) |
Message Set ID |
MessageSetID |
SH |
1 |
(0000,5020) |
End Message ID |
EndMessageID |
SH |
1 |
(0000,5110) |
Display Format |
DisplayFormat |
LT |
1 |
(0000,5120) |
Page Position ID |
PagePositionID |
LT |
1 |
(0000,5130) |
Text Format ID |
TextFormatID |
CS |
1 |
(0000,5140) |
Normal/Reverse |
NormalReverse |
CS |
1 |
(0000,5150) |
Add Gray Scale |
AddGrayScale |
CS |
1 |
(0000,5160) |
Borders |
Borders |
CS |
1 |
(0000,5170) |
Copies |
Copies |
IS |
1 |
(0000,5180) |
Command Magnification Type |
CommandMagnificationType |
CS |
1 |
(0000,5190) |
Erase |
Erase |
CS |
1 |
(0000,51A0) |
Print |
Print |
CS |
1 |
(0000,51B0) |
Overlays |
Overlays |
US |
1-n |
Note
For attributes that were present in ACR-NEMA 1.0 and 2.0 and that have been retired, the specifications of Value Repres- entation and Value Multiplicity provided are recommendations for the purpose of interpreting their values in objects created in accordance with earlier editions of this Standard. These recommendations are suggested as most appropriate for a par- ticular attribute; however, there is no guarantee that historical objects will not violate some requirements or specified VR and/or VM.
- Standard -
DICOM PS3.7 2020a - Message Exchange |
Page 127 |
FUsageoftheP-DATAServiceBytheDICOM
Application Entity (Normative)
How DICOM messages are encapsulated into the P-DATA Service by the DICOM Application Entity is specified in PS3.8. Note
Identical text to that in PS3.8 was formerly duplicated here.
