9.3.5.2 C-ECHO-RSP​

The C-ECHO-RSP Message contains fields as defined in Table 9.3-13 and in Annex C. Each field shall conform to DICOM encoding​ and Value Representation as defined in PS3.5. Fields are required as specified in the C-ECHO service definition unless otherwise​ noted in Table 9.3-13. Fields not specified in the C-ECHO service definition but present in Table 9.3-13 are required by the DIMSE-​ C protocol.​

Table 9.3-13. C-ECHO-RSP Message Fields​

9.3.5.3 C-ECHO Protocol Procedures​

The C-ECHO procedures are initiated by the invoking DIMSE Service User issuing a C-ECHO request primitive. On receipt of the C-​ ECHO request primitive the DIMSE-C protocol machine shall:​

•​construct a Message conveying the C-ECHO-RQ​

•​send the Message using the P-DATA request service (see 8.1)​

On receipt of a Message conveying a C-ECHO-RQ the DIMSE-C protocol machine shall issue a C-ECHO indication primitive to the​ performing DIMSE Service User.​

On receipt of a C-ECHO response primitive, issued by the performing DIMSE Service User, the DIMSE-C protocol machine shall:​

•​construct a Message conveying the C-ECHO-RSP​

•​send the Message using the P-DATA request service (see 8.1)​

On receipt of a Message conveying a C-ECHO-RSP the DIMSE protocol machine shall issue a C-ECHO confirmation primitive to the​ invoking DIMSE Service User, thus completing the C-ECHO procedure.​

- Standard -​

10 DIMSE-N​

10.1 Services​

The following sections describe the DIMSE-N Services. The behavior of these services is also described in PS3.4. The Affected SOP​ Class UID in the DIMSE-N command need not match the SOP Class UID in the Presentation Context negotiated for the association​ over which the DIMSE-N command has been sent. PS3.4 specifies which combinations are valid.​

10.1.1 N-EVENT-REPORT Service​

The N-EVENT-REPORT service is used by a DIMSE Service User to report an event to a peer DIMSE Service User. It is a confirmed​ service.​

10.1.1.1 N-EVENT-REPORT Parameters​

Table 10.1-1 lists the parameters for this service.​

Table 10.1-1. N-EVENT-REPORT Parameters​

10.1.1.1.1 Message ID​

This parameter identifies the operation. It is used to distinguish this operation from other notifications or operations that the DIMSE​ ServiceProvidermayhaveinprogress.NotwoidenticalvaluesfortheMessageID(0000,0110)shallbeusedforoutstandingoperations​ or notifications.​

Note​

TheMessageID(0000,0110)isrecommendedtobeuniquewithinthescopeofanAssociation,tosupportdebugprocedures.​

10.1.1.1.2 Message ID Being Responded To​

ThisparameterspecifiestheMessageID(0000,0110)ofthenotificationrequest/indicationtowhichthisresponse/confirmationapplies.​

10.1.1.1.3 Affected SOP Class UID​

For the request/indication, this parameter specifies the SOP Class of the SOP Instance for the event. It may be included in the re-​ sponse/confirmation. If included in the response/confirmation, this parameter shall be equal to the value in the request/indication.​

10.1.1.1.4 Affected SOP Instance UID​

For the request/indication, this parameter specifies the SOP Instance for the event. It may be included in the response/confirmation.​ If included in the response/confirmation, this parameter shall be equal to thevalue in the request/indication.​

- Standard -​

10.1.1.1.5 Event Type ID​

Thisparameterspecifiesthetypeofeventbeingreported.Itmaybeincludedinthesuccessresponse/confirmationandshallbeincluded​ if the Event Reply parameter is included.​

Note​

Service Class Specifications contained in PS3.4 defines any application usage of the Event Type ID parameter.​

10.1.1.1.6 Event Information​

This application-specific parameter contains information that the invoking DIMSE Service User is able to supply about the event.​ Note​

Service Class Specifications contained in PS3.4 defines any application usage of the Event Information parameter.​

10.1.1.1.7 Event Reply​

Thisapplication-specificparametercontainstheoptionalreplytotheeventreport.Itmayonlybeincludedinthesuccessresponse/con-​ firmation.​

Note​

Service Class Specifications contained in PS3.4 defines any application usage of the Event Reply parameter.​

10.1.1.1.8 Status​

This parameter contains the error or success notification for the operation. It shall be included by the performing DIMSE Service User​ in any response/confirmation. The following types of status may occur (see also Annex C):​

•​Class-Instance conflict (0119H) - the specified SOP Instance is not a member of the specified SOP class.​ •​Duplicate invocation (0210H) - the Message ID (0000,0110) specified is allocated to another notification or operation.​ •​Invalid argument value (0115H) - the event information value specified was out of range or otherwise inappropriate.​ •​Invalid SOP Instance (0117H) - the SOP Instance UID specified implied a violation of the UID construction rules.​

•​Mistyped argument (0212H) - one of the parameters supplied has not been agreed for use on the Association between the DIMSE​ Service Users.​

•​No such argument (0114H) - the event information specified was not recognized.​ •​No such Event Type (0113H) - the event type specified was not recognized.​ •​No such SOP Class (0118H) - the SOP Class was not recognized.​

•​No such SOP Instance (0112H) - the SOP Instance was not recognized.​

•​Processing Failure (0110H) - a general failure in processing the operation was encountered.​ •​Resource Limitation (0213H) - the operation was not performed due to resource limitation.​ •​Success (0000H) - successful notification.​

•​Unrecognized operation (0211H) - the operation is not one of those agreed between the DIMSE Service Users.​

10.1.1.2 N-EVENT-REPORT Service Procedures​

The following N-EVENT-REPORT procedures apply:​

- Standard -​

a.​The invoking DIMSE Service User reports an event to the performing DIMSE Service User by issuing an N-EVENT-REPORT​ request primitive to the DIMSE Service Provider.​

b.​The DIMSE Service Provider issues an N-EVENT-REPORT indication primitive to the performing DIMSE Service User.​

c.​The performing DIMSE Service User reports acceptance or rejection of the N-EVENT-REPORT request primitive by issuing an​ N-EVENT-REPORT response primitive to the DIMSE Service Provider.​

d.​TheDIMSEServiceProviderissuesanN-EVENT-REPORTconfirmationprimitivetotheinvokingDIMSEServiceUser,completing​ the N-EVENT-REPORT notification.​

TheperformingDIMSEServiceUsermayreturnanN-EVENT-REPORTresponseprimitivewiththestatusofFailedorRefusedbefore​ the entire N-EVENT-REPORT indication (Data Set) has been completely transmitted by the invoking DIMSE Service User. A N-​ EVENT-REPORT response primitive with the status of Success or Warning shall not be returned until the entire N-EVENT-REPORT​ indication has been received by the performing DIMSE Service User.​

Note​

Such an occurrence of a "Failed" response is often called an early failed response.​

10.1.2 N-GET Service​

The N-GET service is used by a DIMSE Service User to retrieve Attribute Values from a peer DIMSE Service User. It is a confirmed​ service.​

10.1.2.1 N-GET Parameters​

Table 10.1-2 lists the parameters for this service.​

Table 10.1-2. N-GET Parameters​

10.1.2.1.1 Message ID​

This parameter identifies the operation. It is used to distinguish this operation from other notifications or operations that the DIMSE​ ServiceProvidermayhaveinprogress.NotwoidenticalvaluesfortheMessageID(0000,0110)shallbeusedforoutstandingoperations​ or notifications.​

Note​

TheMessageID(0000,0110)isrecommendedtobeuniquewithinthescopeofanAssociation,tosupportdebugprocedures.​

10.1.2.1.2 Message ID Being Responded To​

This parameter specifies the Message ID (0000,0110) of the operation request/indication to which this response/confirmation applies.​

- Standard -​

10.1.2.1.3 Requested SOP Class UID​

This parameter specifies the SOP Class for which Attribute Values are to be retrieved.​

10.1.2.1.4 Requested SOP Instance UID​

This parameter specifies the SOP Instance for which Attribute Values are to be retrieved.​

10.1.2.1.5 Attribute Identifier List​

ThisparametercontainsasetofAttributeidentifiersforwhichtheAttributeValuesaretobereturnedbytheperformingDIMSEService​ User. If this parameter is omitted, all Attribute identifiers are assumed. The definitions of the Attributes are found in the specification​ of the Information Object Definition in PS3.3.​

10.1.2.1.6 Affected SOP Class UID​

This parameter may be included in the response/confirmation. If included in the response/confirmation, this parameter shall be equal​ to the Requested SOP Class UID parameter value used in the request/indication.​

10.1.2.1.7 Affected SOP Instance UID​

This parameter specifies the SOP Instance for which Attribute Values are returned. It may be included in any response/confirmation​ and when included shall be equal to the Requested SOP Instance UID (0000,1001) parameter value used in the invocation.​

10.1.2.1.8 Attribute List​

This parameter contains the set of Attribute identifiers and values that are returned by the performing DIMSE Service User. It shall​ be included in the success response/confirmation.​

10.1.2.1.9 Status​

This parameter contains the error or success notification for the operation. It shall be included by the performing DIMSE Service User​ in any response/confirmation. The following types of status may occur (see also Annex C):​

•​Attribute list error (0107H) - one or more Attribute Values were not read because the specified Attribute was not recognized. The​ Attribute Values that could be read are returned.​

•​Class-Instance conflict (0119H) - the specified SOP Instance is not a member of the specified SOP Class.​

•​Duplicate invocation (0210H) - the Message ID (0000,0110) specified is allocated to another notification or operation.​

•​Invalid SOP Instance (0117H) - the SOP Instance UID specified implied a violation of the UID construction rules.​

•​Mistyped argument (0212H) - one of the parameters supplied has not been agreed for use on the Association between the DIMSE​ Service Users.​

•​No such SOP Class (0118H) - the SOP Class was not recognized.​

•​No such SOP Instance (0112H) - the SOP Instance was not recognized.​

•​Processing Failure (0110H) - a general failure in processing the operation was encountered.​

•​Resource Limitation (0213H) - the operation was not performed due to resource limitation.​

•​Success (0000H) - successful operation.​

•​Unrecognized operation (0211H) - the operation is not one of those agreed between the DIMSE Service Users.​

•​Refused: Not authorized (0124H) - the DIMSE Service User was not authorized to invoke the operation​

•​Warning (Status value is Service Class specific): not all optional attributes were returned by DIMSE Service User​

•​Failed (Status value is Service Class specific): DIMSE Service User failed to complete the operation​
