D.1.2 Meta Service-Object Pair Group UID​

Each Service Class Definition may optionally define one or more Meta Service-Object Pair Classes each being identified by a Meta​ SOP Class UID. Each Meta SOP Class represents the union of a set of SOP Classes defined in the Service Class.​

By setting the Abstract Syntax Name to a specific Meta SOP Class UID value, DICOM Application Entities may negotiate Service​ Class operations and/or notifications for a set of defined SOP Classes using a single Abstract Syntax. Figure D.1-2 depicts this.​

+IOD A

IOD A

Figure D.1-2. SOP Class UIDs and Meta SOP Class UIDs and Abstract Syntax Names​

D.2 Transfer Syntaxes​

Transfer Syntaxes define a set of encoding rules used to unambiguously represent one or more Abstract Syntaxes. It allows commu-​ nicating DICOM AEs to negotiate the encoding techniques they are able to support (e.g., byte ordering, compression, etc.).​

D.3 Association Establishment​

Association establishment is used to negotiate the type of data to be exchanged and how the data will be encoded. DICOM AEs es-​ tablish Associations by using the ACSE A-ASSOCIATE Service as defined by Part 8 of the DICOM Standard. Three key parameters​ conveyed in the A-ASSOCIATE Service are the Application Context, Presentation Context, and the User Information Items. The fol-​ lowing section discusses these negotiation parameters.​

Note: The A-ASSOCIATE Service is performed only once at Association established time. The examples shown in this Section sep-​ arate the negotiation parameters for clarification purposes only. Readers should remember that only one A-ASSOCIATE request is​ offered for each Association and it contains all of the negotiation parameters.​

D.3.1 Application Context​

An Application Context explicitly defines the set of Application Service Elements, related options and any other information necessary​ for the inter-working of DICOM AEs on an Association.​

The Application Context provides the highest level of negotiation, therefore, a very high level definition. Only one Application Context​ shall be offered per Association. DICOM specifies a single Application Context Name that defines the DICOM Application Context​ (applicable for this Standard and potentially later versions).​

Note​

For complete specification see Annex A.​

D.3.2 Presentation Contexts Negotiation​

A Presentation Context defines the presentation of the data on an Association. It provides a lower level of negotiation and one or​ more Presentation Contexts can be offered and accepted per Association.​

- Standard -​

A Presentation Context consists of three components, a Presentation Context ID, an Abstract Syntax Name, and a list of one or more​

Transfer Syntax Names.​

Only one Abstract Syntax shall be offered per Presentation Context. However, multiple Transfer Syntaxes may be offered per​ Presentation Context, but only one shall be accepted.​

For each SOP Class or Meta SOP Class a Presentation Context must be negotiated such that this Presentation Context supports​ the associated Abstract Syntax and a suitable Transfer Syntax. Presentation Contexts will be identified within the scope of a specific​ Association by a Presentation Context ID.​

Figure D.3-1 provides an illustration of Presentation Context Negotiation with the key points as follows:​

a.​the Association-requester may offer multiple Presentation Contexts per Association.​

b.​each Presentation Context supports one Abstract Syntax (related to a SOP Class or Meta SOP Class) and one or more Transfer​ Syntaxes.​

c.​the Association-acceptor may accept or reject each Presentation Context individually.​

d.​the Association-acceptor selects a suitable Transfer Syntax for each Presentation Context accepted.​

DICOM AE “A”

Figure D.3-1. Presentation Contexts Negotiation​

D.3.3 DICOM Application Association Information​

Peer DICOM AEs negotiate, at Association establishment, a number of features related to the DIMSE protocol by using the ACSE​ User Information Item of the A-ASSOCIATE request. This Section discusses these features.​

When the Association is established between peer DIMSE Service Users the Kernel Functional Unit shall be assumed; therefore, the​ Kernel Functional Unit shall not be included in the A-ASSOCIATE User Information item.​

- Standard -​

D.3.3.1 Maximum Length Application PDU Notification​

The Maximum Length notification allows communicating AEs to limit the size of the data for each P-DATA indication. Each DICOM​ AE defines the maximum PDU size it can receive on this Association. Therefore, different maximum lengths can be specified for each​ direction of data flow on an Association. This notification is required. Figure D.3-2 illustrates the Maximum Length notification.​

Note​

For complete specification see PS3.8.​

DICOM AE “A”

Figure D.3-2. Maximum Length PDU Negotiation​

D.3.3.2 Implementation Identification Notification​

The implementation identification notification allows implementations of communicating AEs to identify each other at Association es-​ tablishmenttime.Itisintendedtoproviderespective(eachnetworknodeknowstheother'simplementationidentity)andnon-ambiguous​ identification in the event of communication problems encountered between two nodes. This negotiation is required.​

Implementation identification relies on two pieces of information:​

•​Implementation Class UID (required)​

•​Implementation Version Name (optional)​

The Implementation Class UID identifies in a unique manner a specific class of implementation. Each node claiming conformance to​ this Standard shall be assigned an Implementation Class UID to distinguish its implementation environment from others. Such Imple-​ mentation Class UIDs shall be registered by the implementing organization per the policies defined in PS3.5. This Standard does not​ specify the policies associated with assigning such a UID.​

Different equipment of the same type or product line (but having different serial numbers) shall use the same Implementation Class​ UID if they share the same implementation environment (i.e., software).​

ThenotificationbyAssociationrequestorsandacceptorsoftheirrespectiveImplementationClassUIDisrequiredforallimplementations​ conforming to this Standard. Figure D.3-3 illustrates the Implementation Class UID notification.​

- Standard -​

Figure D.3-3. Implementation Class UID Notification​

In addition to the Implementation Class UID, an option is provided to convey an Implementation Version Name of up to 16 characters.​ Figure D.3-4 illustrates the Implementation Version Name notification. This Standard does not specify the structure and policies as-​ sociated with such an Implementation Version Name. The absence of the Implementation Version Name requires that the use of the​ same Implementation Class UID by two nodes guarantees that these use the same version of implementation.​

Note​

As the UID shall not be parsed (their structure is not intended to convey any semantic significance beyond uniqueness), this​ optionalImplementationVersionNameprovidesanadequatemechanismtodistinguishtwoversionsofthesameimplement-​ ation (same Implementation Class UID).​

D.3.3.2.1 Implementation Class UID Sub-Item Structure (A-ASSOCIATE-RQ)​

The Implementation Class UID Sub-Item shall be made of a sequence of mandatory fixed length fields followed by a variable field.​ Only one Implementation Class UID Sub-Item shall be present in the User Data Item of the A-ASSOCIATE-RQ. Table D.3-1 shows​ the sequence of the mandatory fields.​

DICOM AE “A”

Figure D.3-4. Implementation Version Name Notification​

Table D.3-1. Implementation Class UID Sub-Item Fields (A-ASSOCIATE-RQ)​

- Standard -​

D.3.3.2.2 Implementation Class UID Sub-Item Structure (A-ASSOCIATE-AC)​

The Implementation Class UID Sub-Item shall be made of a sequence of mandatory fixed length fields followed by a variable field.​ Only one Implementation Class UID Sub-Item shall be present in the User Data Item of the A-ASSOCIATE-AC. Table D.3-2 shows​ the sequence of the mandatory fields.​

Table D.3-2. Implementation UID Sub-Item Fields (A-ASSOCIATE-AC)​

D.3.3.2.3 Implementation Version Name Structure (A-ASSOCIATE-RQ)​

The Implementation Version Name Sub-Item shall be made of a sequence of mandatory fixed length fields followed by a variable​ field. Only one Implementation Version Name Sub-Item shall be present in the User Data Item of the A-ASSOCIATE-RQ. Table D.3-​ 3 shows the sequence of the mandatory fields.​

Table D.3-3. Implementation Version Name Sub-Item Fields (A-ASSOCIATE-RQ)​

D.3.3.2.4 Implementation Version Name Structure (A-ASSOCIATE-AC)​

The Implementation Version Name Sub-Item shall be made of a sequence of mandatory fixed length fields followed by a variable​ field. Only one Implementation Version Name Sub-Item shall be present in the User Data Item of the A-ASSOCIATE-AC. Table D.3-​ 4 shows the sequence of the mandatory fields.​

Table D.3-4. Implementation Version Name Sub-Item Fields (A-ASSOCIATE-AC)​
