8 Protocol Overview​

8.1 DIMSE Protocol​

This Section provides an overview of the DIMSE protocol machine. The DIMSE protocol machine defines the procedures and the​ encoding rules necessary to construct Messages used to exchange command requests and responses between peer DIMSE Service​ Users (e.g., two DICOM Application Entities). The relationship between Messages and the different types of service primitives is​ shown in Figure 7-1.​

TheDIMSEprotocolmachineacceptsDIMSEServiceUserrequestandresponseserviceprimitivesandconstructsMessagesdefined​ by the procedures defined in 9.3 and 10.3. The DIMSE protocol machine accepts Messages and passes them to the DIMSE Service​ User by the means of indication and confirmation service primitives.​

Procedures define the rules for the transfer of Messages that convey command requests and responses. These rules define interpret-​ ation of the various fields in the command part of the Message. They do not define what an invoking DIMSE Service User should do​ with the information (the Data Set part of the Message) it requested nor how a performing DIMSE Service User should process the​ operation.​

Messages may be fragmented. The fragmentation of Messages exchanged between peer DICOM Application Entities and the P-​ DATA service used to exchange these Message fragments are defined in Annex F.​

Note​

These Message fragments are called Application Protocol Data Units (APDUs) by the OSI construct.​

The invoking DIMSE Service User request primitive results in a Message carrying a Command Request (with an optional associated​ Data Set). Each Message induces an indication primitive to the performing DIMSE Service User.​

The performing DIMSE Service User response primitives result in a Message carrying a Command Response (with an optional asso-​ ciated Data Set). Each Message induces a confirmation primitive to the invoking DIMSE Service User.​

8.2 Association Protocol​

The establishment of an Association involves two DIMSE Service Users, one that is the Association-requester and one that is the​ Association-acceptor.ADIMSEServiceUsermayinitiateanAssociationestablishmentbyusingtheA-ASSOCIATEservicedescribed​ in PS3.8.​

IncludedintheparametersoftheA-ASSOCIATEserviceistheApplicationContextthatspecifies,amongotherthings,therulesrequired​ for the coordination of initialization information corresponding to different DICOM Application Entities. The Application Contexts per-​ mitted for DIMSE are specified in Annex A.​

8.3 Conformance​

Implementers conform to the DIMSE protocol only by conformance to a SOP class as defined in PS3.2 and PS3.4. Implementers do​ not conform directly to the DIMSE protocol, and are not required to include a statement about DIMSE conformance in conformance​ statements except as required in PS3.4.​

- Standard -​

- Standard -​

9 DIMSE-C​

9.1 Services​

9.1.1 C-STORE Service​

The C-STORE service is used by a DIMSE Service User to store a composite SOP Instance on a peer DIMSE Service User. It is a​ confirmed service.​

9.1.1.1 C-STORE Parameters​

Table 9.1-1 lists the parameters of this service.​

Table 9.1-1. C-STORE Parameters​

9.1.1.1.1 Message ID​

This parameter identifies the operation. It is used to distinguish this operation from other notifications or operations that the DIMSE​ ServiceProvidermayhaveinprogress.NotwoidenticalvaluesfortheMessageID(0000,0110)shallbeusedforoutstandingoperations​ or notifications.​

Note​

1.​Inclusion of this parameter in the confirmation was permitted in previous versions of this Standard but this mode of use​ is now retired. This parameter may be included in the confirmation but in such a case the invoking DIMSE Service User​ should not attach any semantic significance to this parameter.​

2.​The Message ID (0000,0110) is recommended to be unique within the scope of an Association, to support debug pro-​ cedures.​

9.1.1.1.2 Message ID Being Responded To​

This parameter specifies the Message ID (0000,0110) of the operation request/indication to which this response/confirmation applies.​

9.1.1.1.3 Affected SOP Class UID​

For the request/indication, this parameter specifies the SOP Class for the storage. It may be included in the response/confirmation.​ If included in the response/confirmation, this parameter shall be equal to the value in the request/indication.​

9.1.1.1.4 Affected SOP Instance UID​

For the request/indication, this parameter specifies the SOP Instance to be stored. It may be included in the response/confirmation.​ If included in the response/confirmation, this parameter shall be equal to the value in the request/indication.​

- Standard -​

9.1.1.1.5 Priority​

This parameter specifies the priority of the C-STORE operation. It shall be one of LOW, MEDIUM, or HIGH.​

9.1.1.1.6 Move Originator Application Entity Title​

This parameter specifies the DICOM AE Title of the DICOM AE that invoked the C-MOVE operation from which this C-STORE sub-​ operation is being performed.​

9.1.1.1.7 Move Originator Message ID​

This parameter specifies the Message ID (0000,0110) of the C-MOVE request/indication primitive from which this C-STORE sub-​ operation is being performed.​

9.1.1.1.8 Data Set​

The Data Set accompanying the C-STORE primitive contains the Attributes of the Composite SOP Instance to be stored.​

9.1.1.1.9 Status​

This parameter contains the error or success notification for the operation. It shall be included by the performing DIMSE Service User​ in the response/confirmation. The following types of status may occur in a response/confirmation (see also Annex C):​

a.​Refused: Out of resources (Status value is Service Class specific) - This indicates that the peer DIMSE Service User was unable​ to store the composite SOP Instance because it was out of resources.​

b.​Refused:SOPClassnotsupported(0112H)-ThisindicatesthatthepeerDIMSEServiceUserwasunabletostorethecomposite​ SOP Instance because the SOP Class is not supported,​

c.​Error: Cannot understand (Status value is Service Class specific) - This indicates that the peer DIMSE Service User was unable​ to store the composite SOP Instance because it Cannot understand certain Data Elements.​

d.​Error: Data Set does not match SOP Class (Status value is Service Class specific) - This indicates that the peer DIMSE Service​ User was unable to store the composite SOP Instance because the Data Set does not match the SOP Class.​

e.​Warning(StatusvalueisServiceClassspecific)-ThisindicatesthatthepeerDIMSEServiceUserwasabletostorethecomposite​ SOP Instance, but detected a probable error.​

f.​ Success (0000H) - This indicates that the composite SOP Instance was successfully stored.​

g.​Duplicateinvocation(0210H)-IndicatesthattheMessageID(0000,0110)specifiedisallocatedtoanothernotificationoroperation.​

h.​Invalid SOP Instance (0117H) - Indicates that the SOP Instance UID specified implied a violation of the UID construction rules.​

i.​ Mistyped argument (0212H) - Indicates that one of the parameters supplied has not been agreed for use on the Association​ between the DIMSE Service Users.​

j.​ Unrecognized operation (0211H) - Indicates that the operation is not one of those agreed between the DIMSE Service Users.​

k.​Refused: Not authorized (0124H) - Indicates that the peer DIMSE Service User was not authorized to store the composite SOP​ Instance.​

9.1.1.2 C-STORE Service Procedures​

The following C-STORE procedures apply:​

a.​The invoking DIMSE Service User requests that the performing DIMSE Service User store a composite SOP Instance by issuing​ a C-STORE request primitive to the DIMSE Service Provider.​

b.​The DIMSE Service Provider issues a C-STORE indication primitive to the performing DIMSE Service User.​

- Standard -​

c.​The performing DIMSE Service User reports acceptance or rejection of the C-STORE request primitive by issuing a C-STORE​ response primitive to the DIMSE Service Provider,​

d.​The DIMSE Service Provider issues a C-STORE confirmation primitive to the invoking DIMSE Service User, completing the C-​ STORE operation.​

The performing DIMSE Service User may return a C-STORE response primitive with the status of Failed or Refused before the entire​ C-STOREindication(DataSet)hasbeencompletelytransmittedbytheinvokingDIMSEServiceUser.AC-STOREresponseprimitive​ with the status of Success or Warning shall not be returned until the entire C-STORE indication has been received by the performing​ DIMSE Service User.​

Note​

Such an occurrence of a "Failed" response is often called an early failed response.​

9.1.2 C-FIND Service​

The C-FIND service is used by a DIMSE Service User to match a set of Attributes against the Attributes of a set of composite SOP​ Instances maintained by a peer DIMSE Service User. It is a confirmed service.​

9.1.2.1 C-FIND Parameters​

See Table 9.1-2.​

Table 9.1-2. C-FIND Parameters​

9.1.2.1.1 Message ID​

This parameter identifies the operation. It is used to distinguish this operation from other notifications or operations that the DIMSE​ ServiceProvidermayhaveinprogress.NotwoidenticalvaluesfortheMessageID(0000,0110)shallbeusedforoutstandingoperations​ or notifications.​

Note​

1.​Inclusion of this parameter in the confirmation was permitted in previous versions of this Standard but this mode of use​ is now retired. This parameter may be included in the confirmation but in such a case the invoking DIMSE Service User​ should not attach any semantic significance to this parameter.​

2.​The Message ID (0000,0110) is recommended to be unique within the scope of an Association, to support debug pro-​ cedures.​

9.1.2.1.2 Message ID Being Responded To​

This parameter specifies the Message ID (0000,0110) of the request/indication to which this response/confirmation applies.​

9.1.2.1.3 Affected SOP Class UID​

For the request/indication, this parameter specifies the SOP Class of the Information Model for the query. It may be included in the​ response/confirmation. If included in the response/confirmation, this parameter shall be equal to the value in the request/indication.​

- Standard -​
