1 Scope and Field of Application​

ThisPartoftheDICOMStandardspecifiestheDICOMMessageServiceElement(DIMSE).TheDIMSEdefinesanApplicationService​ Element (both the service and protocol) used by peer DICOM Application Entities for the purpose of exchanging medical images and​ related information.​

The DIMSE provides its services by relying on the DIMSE protocol. The DIMSE protocol defines the encoding rules necessary to​ construct Messages. A Message is composed of a Command Set (defined in this Part of the DICOM Standard) followed by a condi-​ tional Data Set (defined in PS3.5).​

This Part specifies:​

•​a set of service primitives provided by the DIMSE Application Service Element​

•​the parameters that are passed in each service primitive​

•​any necessary information for the semantic description of each service primitive​

•​the procedures applicable to the service primitives​

•​the Abstract Syntax of the DICOM composite and normalized command protocol and the associated encoding rules to be applied​

•​procedures for the correct interpretation of protocol control information​

•​the conformance requirements to be met by implementation of this Part of the Standard​

•​the Application Context required for DICOM Application Entities​

•​the Association requirements of DICOM Application Entities​

•​the Application Association Information for DICOM Application Entities​

This Part is related to other parts of the DICOM Standard in that:​

•​PS3.3, Information Object Definitions, specifies the set of Information Object Definitions to which the services defined in this Part​ may be applied​

•​PS3.5, Data Structure and Encoding, addresses the encoding rules necessary to construct a conditional Data Set that is conveyed​ in a Message as specified in this Part​

•​This Part defines the protocols and services required to accomplish the Service Classes described in PS3.4​

- Standard -​

- Standard -​

2 Normative References​

The following Standards contain provisions that, through reference in this text, constitute provisions of this Standard. At the time of​ publication, the editions indicated were valid. All Standards are subject to revision, and parties to agreements based on this Standard​ are encouraged to investigate the possibilities of applying the most recent editions of the Standards indicated below.​

[ISO/IEC Directives, Part 2] ISO/IEC. 2016/05. 7.0. Rules for the structure and drafting of International Standards. http://www.iec.ch/​ members_experts/refdocs/iec/isoiecdir-2%7Bed7.0%7Den.pdf .​

[ISO 7498-1] ISO. 1994. Information Processing Systems - Open Systems Interconnection - Basic Reference Model.​

[ISO/TR 8509] ISO. Information Processing Systems - Open Systems Interconnection - Service Conventions. ISO/TR 8509 has been​ withdrawn. See ISO/IEC 2382-26:1993 Information technology - Vocabulary - Part 26: Open systems interconnection .​

[ISO8649]ISO.1988.Informationprocessingsystems-OpenSystemsInterconnection-ServicedefinitionfortheAssociationControl​ Service Element (ACSE).​

[ISO 8822] ISO. 1988. Information processing systems - Open Systems Interconnection - Connection oriented presentation service​ definition.​

[ISO/IEC 9595] ISO. 1991. Information processing systems - Open Systems Interconnection - Common Management Information​ Service Definition.​

[ISO/IEC 9834-1] ISO. 2012. Information processing systems - Open Systems Interconnection - Procedures for the operation of OSI​ Registration Authorities: General procedures and top arcs of the ASN.1 Object Identifier tree.​

[RFC1510] IETF. September 1993. The Kerberos Network Authentication Service (V5). http://tools.ietf.org/html/rfc1510 .​

[RFC2289] IETF. February 1998. A One-Time Password System. http://tools.ietf.org/html/rfc2289 .​

[RFC6750] IETF. October 2012. The OAuth 2.0 Authorization Framework: Bearer Token Usage. http://tools.ietf.org/html/rfc6750 .​

[RFC7519] IETF. May 2015. JSON Web Token (JWT). http://tools.ietf.org/html/rfc7519 .​

[SAML] OASIS. 15 March 2005. SAML Assertions and Protocols for the OASIS Security Assertion Markup Language (SAML) V2.0​ OASIS Standard. https://docs.oasis-open.org/security/saml/v2.0/saml-core-2.0-os.pdf .​
