DICOM PS3.7 2020a - Message Exchange |
Page 21 |
3 Definitions
For the purposes of this Standard the following definitions apply.
3.1 Reference Model Definitions
This Part of the Standard is based on the concepts developed in [ISO 7498-1] and makes use of the following terms defined in it:
ApplicationEntity |
See [ISO 7498-1]. |
Application Process |
See [ISO 7498-1]. |
Protocol |
See [ISO 7498-1]. |
Protocol Data Unit |
See [ISO 7498-1]. |
Service |
See [ISO 7498-1]. |
Transfer Syntax |
See [ISO 7498-1]. |
3.2 Service Conventions Definitions
This Part of the Standard makes use of the following terms defined in [ISO/TR 8509]:
Service Provider |
See [ISO/TR 8509]. |
Service User |
See [ISO/TR 8509]. |
Confirmed Service |
See [ISO/TR 8509]. |
Non-confirmed Service |
See [ISO/TR 8509]. |
Primitive |
See [ISO/TR 8509]. |
Request (Primitive) |
See [ISO/TR 8509]. |
Indication (Primitive) |
See [ISO/TR 8509]. |
Response (Primitive) |
See [ISO/TR 8509]. |
Confirm (Primitive) |
See [ISO/TR 8509]. |
3.3 Presentation Service Definitions
This Part of the Standard makes use of the following terms defined in [ISO 8822]:
Abstract Syntax |
See [ISO 8822]. |
Abstract Syntax Name |
See [ISO 8822]. |
Presentation Context |
See [ISO 8822]. |
Presentation Data Value |
See [ISO 8822]. |
3.4 ACSE Service Definitions
This Part of the Standard makes use of the following terms defined in [ISO 8649]:
Association See [ISO 8649].
- Standard -
Page 22 |
DICOM PS3.7 2020a - Message Exchange |
Application Context |
See [ISO 8649]. |
Association Control Service |
See [ISO 8649]. |
Element (ACSE) |
|
Association Initiator |
See [ISO 8649]. |
3.5 CMIS Service Definitions
This Part of the Standard makes use of the following terms defined in [ISO/IEC 9595]:
Functional Unit |
See [ISO/IEC 9595]. |
Kernel Functional Unit |
See [ISO/IEC 9595]. |
3.6 DICOM Introduction and Overview Definitions
This Part of the Standard makes use of the following terms defined in PS3.1:
Attribute |
Attribute. |
Command |
Command. |
Command Stream |
Command Stream. |
Data Stream |
Data Stream. |
Message |
Message. |
Service-Object Pair Class (SOP |
Service-Object Pair Class (SOP Class). |
Class) |
|
3.7 DICOM Upper Layer Service Definitions
This Part of the Standard makes use of the following terms defined in PS3.8:
DICOM Upper Layer Service DICOM Upper Layer Service.
3.8 DICOM Service Class Definitions
This Part of the Standard makes use of the following terms defined in PS3.4:
Service Class |
Service Class. |
Service Class User (SCU) |
Service Class User (SCU). |
Service Class Provider (SCP) |
Service Class Provider (SCP). |
Service-Object Pair Instance |
Service-Object Pair Instance (SOP Instance). |
(SOP Instance) |
|
Related General SOP Class |
Related General SOP Class. |
3.9 DICOM Data Structures and Encoding Definitions
This Part of the Standard makes use of the following terms defined in PS3.5:
Data Element |
Data Element. |
Data Set |
Data Set. |
- Standard -
|
DICOM PS3.7 2020a - Message Exchange |
Page 23 |
Unique Identifier (UID) |
Unique Identifier (UID). |
|
3.10 DICOM Message Exchange Definitions |
|
|
The following definitions are commonly used in this Part of the Standard: |
|
|
DICOM Message Service |
The particular Application Service Element defined in this Part of the DICOM Standard. |
|
Element (DIMSE) |
|
|
DIMSE-C Services |
A subset of the DIMSE services that supports operations on Composite SOP Instances related |
|
|
to composite Information Object Definitions with peer DIMSE Service Users. |
|
DIMSE-N Services |
A subset of the DIMSE services that supports operations and notifications on Normalized SOP |
|
|
Instances related to Normalized Information Object Definitions with peer DIMSE Service Users. |
|
DIMSE Service Group (DSG) |
A specific set of one or more DIMSE Services that define the operations and/or notifications that |
|
|
can be performed on a data structure. |
|
DIMSE Service Provider |
AnabstractionofthetotalityofthoseentitiesthatprovideDIMSEservicestopeerDIMSEService |
|
|
Users. |
|
DIMSE Service User |
That part of an Application Entity that makes use of the DICOM Message Service Element. |
|
Extended Negotiation |
Exchange of application information by peer DICOM AEs at Association establishment, defined |
|
|
by specific Service Class specifications. |
|
Implementation Class UID |
The unique identifier of a specific class of implementation. |
|
Invoking DIMSE Service User |
The DIMSE Service User that invokes a DIMSE operation or notification. |
|
PerformingDIMSEServiceUser |
The DIMSE Service User that performs a DIMSE operation or notification invoked by a peer |
|
|
DIMSE Service User. |
|
- Standard -
Page 24 |
DICOM PS3.7 2020a - Message Exchange |
- Standard -
DICOM PS3.7 2020a - Message Exchange |
Page 25 |
4 Symbols and Abbreviations
The following symbols and abbreviations are used in this Part of the Standard.
ACR |
American College of Radiology |
ACSE |
Association Control Service Element |
ASCII |
American Standard Code for Information Interchange |
AE |
Application Entity |
ANSI |
American National Standards Institute |
CEN TC251Comite Europeen de Normalisation - Technical Committee 251 - Medical Informatics
CMIS |
Common Management Information Service |
CMISE |
Common Management Information Service Element |
DICOM |
Digital Imaging and Communications in Medicine |
DIMSE |
DICOM Message Service Element |
DIMSE-C |
DICOM Message Service Element - Composite |
DIMSE-N |
DICOM Message Service Element - Normalized |
HL7 |
Health Level 7 |
IEEE |
Institute of Electrical and Electronics Engineers |
ISO |
International Standards Organization |
JIRA |
Japan Medical Imaging and Radiological Systems Industries Association |
NEMA |
National Electrical Manufacturers Association |
OSI |
Open Systems Interconnection |
PDU |
Protocol Data Unit |
PDV |
Protocol Data Value |
SOP |
Service-Object Pair |
TCP/IP |
Transmission Control Protocol/Internet Protocol |
VM |
Value Multiplicity |
VR |
Value Representation |
UID |
Unique Identifier |
UL |
Upper Layers |
